Item Specification
Print Technology
• Dye-sublimation / resin thermal transfer
• Rewritable technology
Print Capabilities
• Single-sided
Print Resolution
• 300 dots per inch (dpi) (300 X 600, 300 X 1200)
Monochrome printing
• Up to 660 single-sided cards per hour
Print Speed
• Full color printing
• Single-sided color ribbon – Up to 175 cards per hour (cph)
Card Capacity
• Input hopper – up to 125 cards
• Output hopper – up to 25 cards (up to 100 optional)
Card Sizes
• Thickness – 0.010 inches to 0.040 inches (0.25mm – 1.016mm)
• Dimension – ID-1, CR-79, CR-80
Operating Environment
• Temperature: 60°F to 95°F (15°C to 35°C)
• Humidity: 20-80 % RH – non condensing
Physical Dimensions
• L 17.4 in x W 8.9 in x H 9 in / 44.2 cm x 22.6 cm x 22.9 cm
Weight
• 11.3 lbs (5.49 kg)
Connectivity
• USB
Supporting Documents
Sigma DS1 Brochure Download PDF
