| Printing Technology | Digital LED Electrophotographic Printing Technology |
| Print Speed | A4 40 ppm |
| First Print Out Time | Approx. 4.5 seconds |
| Warm-up Time | 17 seconds |
| Processor Speed | 667MHz |
| Printing Resolution | 1200 x 1200 dpi |
| Printer fonts | PostScript emulation 136 fonts, PCL emulation 87 scalable fonts, 4 bitmap fonts |
| Dot matrix fonts | Epson FX and IBM PPR at various pitches |
| Barcode | 10 types of one dimension with 26 variations: UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, Interleaved2of5, Code39, Code 128, EAN/UCC-128, CODABAR, ZIP+4POSTNET; 2 types of two dimension: PDF417, QR code |
| Paper Capacity | Tray 1: 250 sheets of 80gsm |
| (Optional) Tray 2: 530 sheets of 80gsm | |
| Multi-purpose tray: 100 sheets of 80gsm | |
| Maximum Paper Capacity | 880 sheets of 80gsm |
| Paper Sizes | Tray 1: A4, A5, B5(JIS), A6, Letter, Legal 13, Legal 14, Executive, Statement |
| Tray 2: A4, A5, B5(JIS), Letter, Legal 13, Legal 14, Executive | |
| Multi-purpose tray: A4, A5, B5(JIS), A6, Letter, Legal 13, Legal 14, Executive, Statement, Envelopes (Monarch, Com-9, Com-10, DL, C5, C6), Custom Size (up to 1321mm length including banners), 4 x 6”, 5 x 7” | |
| Duplex: A4, B5(JIS), Letter, up to Legal 14, Executive | |
| Paper Weight | Tray 1: 60 to 120gsm |
| (Optional) Tray 2: 60 to 120gsm | |
| Multi-purpose tray: 60 to 163gsm | |
| Duplex | Standard |
| Output Capacity | Face Down: Max. 150 sheets of 80gsm |
| Face Up: Max. 100 sheets of 80gsm | |
| Memory (Std./Max.) | 512MB RAM; 3GB eMMC/512MB RAM; 3GB eMMC |
| Environment | Operating temperature/ humidity: 10°C to 32°C/ 20% to 80% RH non-condensing |
| Storage temperature/ humidity: -10°C to 43°C/ 10% to 90% RH non-condensing | |
| Power Supply | 230 VAC +/- 10%, 50 or 60Hz +/-2% |
| Power Consumption | Typical: 600W |
| Max: 900W | |
| Idle: 80W | |
| Power Save: 7W | |
| Deep Sleep: 1.4W | |
| Auto-Off: 0.5W | |
| Noise Level | Operating: 55dB(A) or less |
| Standby: 30dB(A) or less | |
| Power save: Background level | |
| Dimensions (WxDxH) | 387 x 364 x 245mm |
| with optional Tray 2: 387 x 364 x 383mm | |
| Weight (includes supplies) | 13 kg |
